Supplemental restraint circuit, with standard air bag for Oldsmobile Aurora II (1999-2003)
Supplemental restraint circuit, with standard air bag
AIR BAG INDICATOR
BLK WIRE
BLK/WHT WIRE
BRN WIRE
CASE GROUND
COMPUTER DATA LINES SYSTEM
DASH INTEGRATION MODULE (DIM) (BEHIND DASH, UNDER RIGHT DASH SOUND INSULATOR)
DATA LINK CONNECTOR (DLC) (PARTIAL) (AT LOWER LEFT SIDE OF DASH) PPL
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
FLAT WIRE
GRY WIRE
HOT IN ON, START
IGNITION
INFLATABLE RESTRAINT I/P MODULE
INFLATABLE RESTRAINT STEERING WHEEL MODULE
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
INSTRUMENT PANEL CLUSTER (IPC)
LEFT FRONT INFLATABLE RESTRAINT SIDE IMPACT MODULE
LOGIC
NCA WIRE
PPL
PPL PPL 1807 1807
REAR FUSE BLOCK (UNDER LEFT REAR SEAT)
RIGHT FRONT INFLATABLE RESTRAINT SIDE IMPACT MODULE
SHORTING BAR
SHORTING BAR SHORTING BAR
SIR FUSE
SWITCH SIGNAL LOW REFERENCE
TAN WIRE
THEFT DETERRENT CONTROL MODULE (UNDERSIDE OF DASH, BEHIND RADIO)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
