Memory mirrors circuit for Oldsmobile Aurora II (1999-2003)
Memory mirrors circuit
BATT +
BATTERY
BLK WIRE
BLK/WHT WIRE
DRIVER 1
DRIVER 1 INPUT
DRIVER 2
DRIVER 2 INPUT
DRIVER DOOR MODULE (INSIDE DRIVER'S DOOR)
DRIVER DOOR SWITCH ASSEMBLY
DRIVER OUTSIDE REARVIEW MIRROR
DRVMDL FUSE
EXIT
HEATING ELEMENT FEED HEATING ELEMENT RETURN
HOT AT ALL TIMES
LEFT/ RIGHT MOTOR
LEFT/ RIGHT MOTOR POSITION SENSOR UP/ DOWN MOTOR POSITION SENSOR
LEFT/RIGHT MOTOR CONTROL LEFT/RIGHT MOTOR CONTROL POSTION SENSORS FEED
LEFT/RIGHT MOTOR POSITION INPUT
MEMORY FUNCTION SWITCH
MIRROR HEATING ELEMENT
NCA WIRE
ORG/ WIRE
PASS MDL FUSE
PASSENGER DOOR MODULE (INSIDE PASSENGER'S DOOR)
PASSENGER OUTSIDE REARVIEW MIRROR
POSTION SENSORS RETURN
PPL
REAR FUSE BLOCK
SIMPLE BUS INTERFACE
TAN/WHT WIRE
UP/ DOWN MOTOR
UP/DOWN MOTOR CONTROL UP/DOWN MOTOR CONTROL
UP/DOWN MOTOR POSITION INPUT
WHT WIRE
YEL WIRE
