Oldsmobile Aurora II (1999-2003) left/right motor position input Wiring diagram
This page shows the only wiring diagram for the component.left/right motor position input, which is found in the car Oldsmobile Aurora II (1999-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left/right motor position input (1 of 1)
BATT +
BATTERY
BLK WIRE
BLK/WHT WIRE
DRIVER 1
DRIVER 1 INPUT
DRIVER 2
DRIVER 2 INPUT
DRIVER DOOR MODULE (INSIDE DRIVER'S DOOR)
DRIVER DOOR SWITCH ASSEMBLY
DRIVER OUTSIDE REARVIEW MIRROR
DRVMDL FUSE
EXIT
HEATING ELEMENT FEED HEATING ELEMENT RETURN
HOT AT ALL TIMES
LEFT/ RIGHT MOTOR
LEFT/ RIGHT MOTOR POSITION SENSOR UP/ DOWN MOTOR POSITION SENSOR
LEFT/RIGHT MOTOR CONTROL LEFT/RIGHT MOTOR CONTROL POSTION SENSORS FEED
LEFT/RIGHT MOTOR POSITION INPUT
MEMORY FUNCTION SWITCH
MIRROR HEATING ELEMENT
NCA WIRE
ORG/ WIRE
PASS MDL FUSE
PASSENGER DOOR MODULE (INSIDE PASSENGER'S DOOR)
PASSENGER OUTSIDE REARVIEW MIRROR
POSTION SENSORS RETURN
PPL
REAR FUSE BLOCK
SIMPLE BUS INTERFACE
TAN/WHT WIRE
UP/ DOWN MOTOR
UP/DOWN MOTOR CONTROL UP/DOWN MOTOR CONTROL
UP/DOWN MOTOR POSITION INPUT
WHT WIRE
YEL WIRE
Go to component -> Memory mirrors circuit -> LEFT/RIGHT MOTOR POSITION INPUT
