Oldsmobile Aurora II (1999-2003) inflatable restraint side impact module- right front Wiring diagram

238 1363 SWITCH SIGNAL LOW REFERENCE AIR BAG INDICATOR BLK WIRE BLK/WHT WIRE BLU WIRE BRN WIRE CASE GROUND COMPUTER DATA LINES SYSTEM DASH INTEGRATION MODULE (DIM) (BEHIND DASH, UNDER RIGHT DASH SOUND INSULATOR) DATA LINK CONNECTOR (DLC) (PARTIAL) (AT LOWER LEFT SIDE OF DASH) PPL DK BLU WIRE DK GRN WIRE FLAT WIRE FLAT WIRE (OR PPL) GRY WIRE HOT IN RUN, START IGNITION INFLATABLE RESTRAINT FRONT END DISCRIMINATING SENSOR INFLATABLE RESTRAINT I/P MODULE INFLATABLE RESTRAINT SIDE IMPACT MODULE- LEFT FRONT INFLATABLE RESTRAINT SIDE IMPACT MODULE- RIGHT FRONT INFLATABLE RESTRAINT STEERING WHEEL MODULE INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL INSTRUMENT PANEL CLUSTER (IPC) LOGIC NCA WIRE ORG/ WIRE PNK PPL WIRE PNK WIRE PPL REAR FUSE BLOCK (UNDER LEFT REAR SEAT) SENSOR SIGNAL LOW REFERENCE SERIAL DATA CLASS 2 SHORTING BAR SHORTING BAR SHORTING BAR SIR FUSE TAN WIRE TAN/ORG WIRE WHT WIRE YEL WIRE
