Oldsmobile Aurora II (1999-2003) console accessory power outlet Wiring diagram
This page shows the only wiring diagram for the component.console accessory power outlet, which is found in the car Oldsmobile Aurora II (1999-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram console accessory power outlet (1 of 1)
ABS FUSE
ASSEMBLY SHIFT CONTROL
AUTOMATIC LEVEL CONTROL COMPRESSOR
AUX PWR FUSE
BLK WIRE
BREAKOUT)
BRN WIRE
C/LTR FUSE
CIGAR FUSE
CIGAR LIGHTER
CIGAR RELAY
COIL
COIL CONTACT
CONSOLE ACCESSORY POWER OUTLET
CONTACT
CONTACT CONTACT
DK GRN WIRE
DRIVER INFORMATION CENTER
ELC FUSE
ELC RELAY
ELECTRONIC BRAKE CONTROL MODULE INSIDE REARVIEW MIRROR
F/PMP FUSE
F/PMP RELAY
FROM REAR FUSE BLOCK
FROM REAR FUSE BLOCK (RR DEFOG RELAY) (DIAGRAM 4 OF 5)
HVAC CONTROL MODULE INSTRUMENT PANEL INTEGRATION MODULE
HVAC FUSE
IGN 3 RR FUSE
IGN-3 RELAY
LEFT AIR TEMPERATURE ACTUATOR
MODE ACTUATOR
NCA WIRE
ORG/ WIRE
PARK RELAY REVERSE RELAY
PNK WIRE
PRK LP RELAY
PRK/REV FUSE
REAR FUSE BLOCK (UNDER LEFT REAR SEAT)
REAR INTEGRATION MODULE (NEAR UPPER LEFT CORNER OF REAR SHELF)
RECIRCULATION ACTUATOR
RED WIRE
REVERSE LOCKOUT CONTROL ACTUATOR
RIGHT AIR TEMPERATURE ACTUATOR INSTRUMENT PANEL INTEGRATION MODULE
UNDERHOOD FUSE BLOCK (AT RIGHT SIDE OF ENGINE COMPARTMENT)
W/ AUTO A/C
W/ AUTO A/C W/O AUTO A/C
Go to component -> Power distribution circuit (5 of 5) -> CONSOLE ACCESSORY POWER OUTLET
