Oldsmobile Aurora II (1999-2003) 1977 1870 ppl ppl computer data lines system Wiring diagram

1783 1870 PPL PPL PPL COMPUTER DATA LINES SYSTEM 1977 1870 PPL PPL COMPUTER DATA LINES SYSTEM AIR CONDITIONING SYSTEM AUTO AUTO PPL BLK WIRE BLK/WHT WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DASH INTEGRATION MODULE (DIM) (RIGHT SIDE OF DASH) DK GRN WIRE DK GRN/WHT WIRE DRL RELAY FLASH TO PASS FOG LAMP SWITCH FOG LP RELAY FOG/ DRL FUSE FRONT HDHIBMR FUSE HDHIBML FUSE HDLOBNL FUSE HDLOBNR FUSE HDLP HI BM RELAY HDLP LO BM RELAY HEADLAMP BEAM SWITCH HEADLAMP DIMMER SWITCH HEADLAMP SWITCH HI LOW HOT AT ALL TIMES HOT IN ON OR START INSTRUMENT PANEL INTEGRATION MODULE (BEHIND A/C CONTROLS) LEFT FRONT FOG LAMP LEFT LOW BEAM HEAD- LAMP LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE NCA WIRE OFF OFF PARK HEAD ORG/ WIRE PNK PNK WIRE PNK WIRE PNK/BLK WIRE PNK/WHT WIRE PPL PPL PPL 1807 1807 PRK LP RELAY REAR REAR FOG LP RELAY REAR FUSE BLOCK (UNDER LEFT REAR SEAT) REAR INTEGRATION MODULE (LEFT CORNER OF REAR SHELF) RED WIRE RIGHT FRONT FOG LAMP RIGHT HIGH BEAM HEAD- LAMP LEFT HIGH BEAM HEAD- LAMP RIGHT LOW BEAM HEAD- LAMP RIGHT REAR FOG LAMP LEFT REAR FOG LAMP RR FOG FUSE TAN WIRE WHT WIRE WIPER/ WASHER SYSTEM YEL WIRE
