Car Wiring Diagrams for Heated seats circuit for Oldsmobile Aurora I (1994-1999)

BACKLIGHT BLK WIRE BLK/WHT WIRE BRN WIRE BRN/WHT WIRE DK BLU WIRE DK BLU/WHT WIRE GRY WIRE HEAT ELEMENTS PWR HEAT ELEMENTS RTN SENSOR INPUT SENOR RETURN HEATED SEATS FUSE HEATER AND A/C PROGRAMMER HEATING ELEMENTS HEATING ELEMENTS THERMISTOR HOT AT ALL TIMES HOT IN RUN I/P FUSE BLOCK IGN 3 FUSE IGN BAT HEAT SW INPUT LO HEAT LED CTRL GRD HI HEAT LED CTRL TEMP STATUS OUTPUT JUMPER LEFT FRONT SEAT COVER LEFT HEATED SEAT CONTROL MODULE (BELOW LEFT FRONT SEAT) LEFT SEAT/ LOCK SWITCH LT BLU WIRE LT BLU/BLK WIRE LT BLU/WHT WIRE NCA WIRE NTC- ON OFF RED WIRE RIGHT FRONT SEAT COVER RIGHT HEATED SEAT CONTROL MODULE (BELOW RIGHT FRONT SEAT) RIGHT REAR POWER DISTRIBUTION CENTER FUSE BLOCK 1 RIGHT SEAT/ LOCK SWITCH THERMISTOR WHT WIRE
