Courtesy lamps circuit for Oldsmobile Aurora I (1994-1999)

49 528 1393 DR OPEN IN 6 9 (OLDS) (BUICK) BLK WIRE BLU WIRE BODY CONTROL MODULE (MALL) (LEFT SIDE OF I/P) CONSOLE COMPARTMENT LAMP CONSOLE COMPARTMENT LAMP SWITCH COURTESY LAMPS SWITCH DK BLU WIRE DR OPEN IN GRY WIRE HOT AT ALL TIMES HOT IN ACC OR RUN HOT IN RUN OR START I/P 1 FUSE I/P COMPARTMENT LAMP I/P COMPARTMENT LAMP SWITCH I/P FUSE BLOCK IGN 1 FUSE INT LMP IN INT LMPS + INT LP FUSE LEFT FRONT COURTESY LAMP LEFT FRONT DOOR COURTESY LAMP LEFT FRONT DOOR WARNING LAMP LEFT REAR DOOR COURTESY/ WARNING LAMP (OLDS) LEFT REAR DOOR LATCH SWITCH (OLDS ONLY) LMP CTRL LT GRN/BLK WIRE LUGGAGE COMPARTMENT LATCH ASSEMBLY LUGGAGE COMPARTMENT LAMP NCA WIRE OLDSMOBILE ORG/ WIRE ORG/BLK WIRE PASSIVE RESTRAINT SYSTEM (BUICK ONLY) PNK BAT WIRE PNK LMP CTRL WIRE PNK WIRE PWR DR LKS FUSE REMOTE FUNCTION ACTUATOR (RFA) MODULE (UNDER REAR PACKAGE SHELF) RIGHT FRONT COURTESY LAMP RIGHT FRONT DOOR LATCH SWITCH RIGHT FRONT DOOR WARNING LAMP RIGHT REAR DOOR COURTESY/ WARNING LAMP (OLDS) RIGHT REAR DOOR LATCH SWITCH (OLDS) ONLY) RIGHT REAR POWER DISTRIBUTION CENTER WHT WIRE WSW FUSE YEL WIRE

BLK WIRE BLU WIRE DK GRN WIRE ENGINE COMPARTMENT LAMP HOT W/LIGHT SWITCH IN HEAD OR PARK I/P FUSE BLOCK INT LP FUSE LEFT FRONT DOME/ READING LAMP AND SWITCH LEFT FRONT ILLUMINATED VANITY MIRROR LEFT RAIL COURTESY LAMP LEFT RAIL LAMP SWITCH LT GRN WIRE OLDS, BUICK ON DR ORG/ WIRE RIGHT FRONT DOME/ READING LAMP AND SWITCH RIGHT FRONT ILLUMINATED VANITY MIRROR RIGHT RAIL COURTESY LAMP RIGHT RAIL LAMP SWITCH WHT WIRE YEL WIRE
