Oldsmobile Aurora I (1994-1999) Driver information center circuit

BLK WIRE BLK/WHT WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DK GRN WIRE GND E, C DATA LINE HEATER AND A/C CONTROL ASSEMBLY HOT AT ALL TIMES HOT IN RUN I/P 1 FUSE I/P FUSE BLOCK IGN IGN 3 FUSE ILLUMINATION (6 BULBS) ILLUMINATION DIMMING INTERIOR LIGHTS SYSTEM (DIMMER MODULE) ORG/ WIRE ORG/BLK WIRE RIGHT REAR POWER DISTRIBUTION CENTER UART DATA LINE BAT
