Car Wiring Diagrams for Forced entry circuit for Oldsmobile Aurora I (1994-1999)

BATTERY BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (LEFT INSTRUMENT PANEL) DK BLU WIRE DK GRN WIRE DOOR LOCK DOOR LOCK INPUT DOOR OPEN INPUT DOOR UNLOCK DOOR UNLOCK INPUT GROUND HEADLAMPS ALARM INPUT HEADLAMPS OUTPUT HORN RLY CTRL HORNS SYSTEM (HORN RELAY) HOT IN RUN, BULB TEST OR START HTO AT ALL TIMES I/P FUSE BLOCK IGN 1 FUSE KEY UNLOCK INPUT LAMP CONTROL MODULE (BEHIND LEFT KICK PANEL) LEFT DOOR LOCK CYLINDER SWITCH UN- LOCK LOCK LEFT FRONT DOOR JAMB SWITCH LEFT REAR DOOR JAMB SWITCH (OLDS ONLY) LF DOOR JAMB INPUT LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE LUGGAGE COMPARTMENT LID TAMPER SWITCH LUGGAGE COMPT AJAR OLDS ORG/ WIRE ORG/BLK WIRE PASSKEY CIRCUIT (SECURITY INDICATOR) PNK IGNITION WIRE PNK WIRE REMOTE FUNCTION ACTUATION MODULE (RIGHT FRONT OF LUGGAGE COMPT) RIGHT DOOR LOCK CYLINDER SWITCH UN- LOCK LOCK RIGHT FRONT DOOR JAMB SWITCH (BUICK) RIGHT FRONT DOOR LOCK ACTUATOR (OLDS) RIGHT REAR DOOR JAMB SWITCH (OLDS ONLY) RIGHT REAR POWER DISTRIBUTION CENTER (UNDER REAR SEAT) I/P 1 FUSE SECURITY INDICATOR TAN WIRE
