Oldsmobile Aurora I (1994-1999) upper solenoid valve wiring diagram
This page shows the only wiring diagram for the component.upper solenoid valve, which is found in the car Oldsmobile Aurora I (1994-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
upper solenoid valve wiring diagram (1 of 1)
BLK WIRE
DEFL INFL
DEFL LOWER LUMBAR
DRIVER SEAT/ LOCK SWITCH
GRY WIRE
HOT AT ALL TIMES
I/P 1 FUSE
INFL UPPER LUMBAR
INFLATE CIRCUIT
LOWER SOLENOID VALVE
LUMBAR CONTROL MODULE
NCA WIRE
ORG/ WIRE
PASSENGER SEAT/ LOCK SWITCH
PPL
PRESSURE CUT-OUT CIRCUIT
PWR ST CIRCUIT BREAKER
RED WIRE
RIGHT REAR POWER DISTRIBUTION CENTER FUSE BLOCK 1
SEAT AIR PUMP DEFLATE CIRCUIT
UPPER SOLENOID VALVE
WHT WIRE
YEL WIRE
Go to component -> Lumbar circuit -> UPPER SOLENOID VALVE
