Oldsmobile Aurora I (1994-1999) trunk lid release actuator (center rear Wiring diagram
This page shows the only wiring diagram for the component.trunk lid release actuator (center rear, which is found in the car Oldsmobile Aurora I (1994-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trunk lid release actuator (center rear (1 of 1)
ASSEMBLY
BLK WIRE
BLK/WHT WIRE
F/DR REL FUSE
FUEL DOOR
FUEL DOOR RELEASE SOLENOID
GRY WIRE
HOT AT ALL TIMES
LT BLU WIRE
MOTOR
OF TRUNK LID NEAR LATCH) PTC
ORG/ WIRE
PNK WIRE
RELAY CONTROL
RELEASE SWITCH
REMOTE FUNCTION ACTUATOR (RFA) MODULE (UNDER REAR PACKAGE SHELF)
TRUNK LID RELEASE ACTUATOR (CENTER REAR
TRUNK LID RELEASE RELAY
TRUNK LID RELEASE SWITCH
TRUNK LID/FUEL DOOR RELEASE SWITCH
VALET SWITCH
WHT WIRE
Go to component -> Trunk & fuel door release circuit -> TRUNK LID RELEASE ACTUATOR (CENTER REAR
