Oldsmobile Aurora I (1994-1999) right rail lamp switch Wiring diagram
This page shows the only wiring diagram for the component.right rail lamp switch, which is found in the car Oldsmobile Aurora I (1994-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rail lamp switch (1 of 1)
BLK WIRE
BLU WIRE
DK GRN WIRE
ENGINE COMPARTMENT LAMP
HOT W/LIGHT SWITCH IN HEAD OR PARK
I/P FUSE BLOCK
INT LP FUSE
LEFT FRONT DOME/ READING LAMP AND SWITCH
LEFT FRONT ILLUMINATED VANITY MIRROR
LEFT RAIL COURTESY LAMP
LEFT RAIL LAMP SWITCH
LT GRN WIRE
OLDS, BUICK
ON DR
ORG/ WIRE
RIGHT FRONT DOME/ READING LAMP AND SWITCH
RIGHT FRONT ILLUMINATED VANITY MIRROR
RIGHT RAIL COURTESY LAMP
RIGHT RAIL LAMP SWITCH
WHT WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (2 of 2) -> RIGHT RAIL LAMP SWITCH
