Oldsmobile Aurora I (1994-1999) pwr dr lks fuse Wiring diagram
This page shows the only wiring diagram for the component.pwr dr lks fuse, which is found in the car Oldsmobile Aurora I (1994-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pwr dr lks fuse (1 of 1)
49 528 1393 DR OPEN IN
6 9 (OLDS) (BUICK)
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (MALL) (LEFT SIDE OF I/P)
CONSOLE COMPARTMENT LAMP
CONSOLE COMPARTMENT LAMP SWITCH
COURTESY LAMPS SWITCH
DK BLU WIRE
DR OPEN IN
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR RUN
HOT IN RUN OR START
I/P 1 FUSE
I/P COMPARTMENT LAMP
I/P COMPARTMENT LAMP SWITCH
I/P FUSE BLOCK
IGN 1 FUSE
INT LMP IN
INT LMPS +
INT LP FUSE
LEFT FRONT COURTESY LAMP
LEFT FRONT DOOR COURTESY LAMP
LEFT FRONT DOOR WARNING LAMP
LEFT REAR DOOR COURTESY/ WARNING LAMP (OLDS)
LEFT REAR DOOR LATCH SWITCH (OLDS ONLY)
LMP CTRL
LT GRN/BLK WIRE
LUGGAGE COMPARTMENT LATCH ASSEMBLY LUGGAGE COMPARTMENT LAMP
NCA WIRE
OLDSMOBILE
ORG/ WIRE
ORG/BLK WIRE
PASSIVE RESTRAINT SYSTEM (BUICK ONLY)
PNK BAT WIRE
PNK LMP CTRL WIRE
PNK WIRE
PWR DR LKS FUSE
REMOTE FUNCTION ACTUATOR (RFA) MODULE (UNDER REAR PACKAGE SHELF)
RIGHT FRONT COURTESY LAMP
RIGHT FRONT DOOR LATCH SWITCH
RIGHT FRONT DOOR WARNING LAMP
RIGHT REAR DOOR COURTESY/ WARNING LAMP (OLDS)
RIGHT REAR DOOR LATCH SWITCH (OLDS) ONLY)
RIGHT REAR POWER DISTRIBUTION CENTER
WHT WIRE
WSW FUSE
YEL WIRE
Go to component -> Courtesy lamps circuit (1 of 2) -> PWR DR LKS FUSE
