Oldsmobile Aurora I (1994-1999) lumbar seat module Wiring diagram
This page shows the only wiring diagram for the component.lumbar seat module, which is found in the car Oldsmobile Aurora I (1994-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lumbar seat module (1 of 1)
1995 VFTC
ABS MAIN RELAY AMBIENT LIGHT SENSOR PANEL DIMMING CONTROL HEAD- LAMP SWITCH
ASH- TRAY LAMP PRNDL LAMP
AUTOMATIC DAY/NIGHT MIRROR
AUXILIARY POWER RECEPTACLE
BLK (OR BLK/WHT) WIRE
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE
BOSE AMPLIFIER RADIO
CONSOLE COMPART- MENT LAMP SWITCH
DATA LINK CONNECTOR
FOG LAMP SWITCH
FRONT CIGAR LIGHTER
FUEL DOOR RELEASE SWITCH
HEATER AND A/C CONTROL ASSEMBLY
I/P COMPART- MENT LAMP/ SWITCH
INSTRUMENT CLUSTER
LAMP CONTROL MODULE
LEFT FOG LAMP
LEFT FRONT SEAT SWITCH MASTER SWITCH ASSEMBLY
LEFT HEATED SEAT CONTROL MODULE
LEFT OUTSIDE MIRROR
LEFT OUTSIDE MIRROR CONTROL SWITCH
LUMBAR SEAT MODULE
MAGNA STEER MODULE
NCA WIRE
OLDSMOBILE (LEFT SIDE OF I/P)
PANEL DIMMING SWITCH
PRNDL LAMP
REMOTE CD PLAYER
SEAT BELT SWITCH
SHIFT INTERLOCK SOLENOID
SHIFT SELECT SWITCH
STEERING COLUMN)
STEERING WHEEL CONTROLS LAMP IGNITION SWITCH
TRACTION CONTROL SWITCH
W/ STEERING WHEEL CONTROLS ONLY
WHT WIRE
Go to component -> Ground distribution circuit (3 of 5) -> LUMBAR SEAT MODULE
