Oldsmobile Aurora I (1994-1999) left heated mirror element Wiring diagram
This page shows the only wiring diagram for the component.left heated mirror element, which is found in the car Oldsmobile Aurora I (1994-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left heated mirror element (1 of 1)
BLK WIRE
BRN WIRE
COMPUTER DATA LINES
DATA LINE
DEFOG SWITCH
FUSE
HEATER-A/C CONTROL
HOT AT ALL TIMES
HOT IN RUN
HTD O/S MIR
HVAC PROGRAMMER (RIGHT SIDE OF I/P)
I/P 1 FUSE
I/P FUSE BLOCK
IGN 3 FUSE
LEFT HEATED MIRROR ELEMENT
LEFT REAR POWER DISTRIBUTION CENTER (BELOW LEFT REAR SEAT)
LOWER ZONE RELAY CTRL
NCA WIRE
ORG/ WIRE
POWER
PPL
REAR DEFOG RELAY (LOWER ZONE)
REAR DEFOG RELAY 2 (UPPER ZONE)
REAR DEFOGGER LOWER ZONE REAR DEFOGGER UPPER ZONE
RED WIRE
RIGHT HEATED MIRROR ELEMENT
RIGHT REAR POWER DISTRIBUTION CENTER (BELOW LEFT REAR SEAT)
RR DEFOG 1 FUSE
RR DEFOG 2 FUSE
SOLID STATE
TAN WIRE
UPPER ZONE RELAY CTRL IGN
WHT WIRE
Go to component -> Defogger circuit -> LEFT HEATED MIRROR ELEMENT
