Oldsmobile Aurora I (1994-1999) backup lights system Wiring diagram
This page shows the only wiring diagram for the component.backup lights system, which is found in the car Oldsmobile Aurora I (1994-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram backup lights system (1 of 1)
ANTI-LOCK BRAKE SYSTEM
BACKUP LIGHTS SYSTEM
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
CENTER HIGH MOUNTED STOP LAMP
CORN- ERING LAMPS LEFT FRONT SIDE MARKER LAMP
DK (BODY HARN, BEHIND RIGHT TAILLAMP RIGHT FRONT PARK/ TURN LAMP
FUSE
GRD
GRN WIRE
GRY/BLK WIRE
HAZARD
HAZARD FLASHER (BEHIND LEFT SIDE OF DASH)
HEADLAMP SWITCH PARK LAMP SWITCH
HOT AT HOT AT ALL TIMES ALL TIMES
HOT IN RUN AND START
HZRD/ STOP LPS
I/P FUSE BLOCK
INSTRUMENT CLUSTER
L PRK LP FUSE
LAMP CONTROL MODULE (BEHIND LEFT SIDE OF DASH)
LEFT FRONT PARK/ TURN LAMP
LEFT REAR TAIL/ STOP/ TURN LAMPS
LEFT TURN INDIC
LEFT TURN, HAZARD
LT (BODY HARN, BEHIND LEFT SIDE OF DASH, UNDER CLUSTER)
LT DK
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
PARK LAMP CTRL
PARK LP
PERIMETER LIGHTING CONTROL
PERIMETER LIGHTING CONTROL RELAY (UNDER LEFT SIDE OF REAR SEAT)
PNK WIRE
PPL
PPL LT
PRM LP
PWR PARK LAMP SWITCH INPUT
R PRK LP FUSE
REMOTE FUNCTION ACTUATOR MODULE (UNDER REAR PACKAGE SHELF)
RIGHT FRONT SIDE MARKER LAMP
RIGHT REAR JUNCTION BLOCK (UNDER LEFT REAR SEAT)
RIGHT REAR TAIL/ STOP/ TURN LAMPS
RIGHT TURN INDIC
RIGHT TURN, HAZARD
STOPLAMP/ BTSI SWITCH (ON BRAKE PEDAL SUPPORT)
TAN WIRE
TURN LPS
TURN SIGNAL FLASHER (BEHIND LEFT SIDE OF DASH)
TURN/ HAZARD SWITCH ASSEMBLY
WHT WIRE
YEL WIRE
