Oldsmobile Alero I (1999-2004) Charging circuit

61 50 29 49 (3.4L) (2.2L) BATTERY BLK WIRE BODY CONTROL MODULE (BCM) (BEHIND RIGHT SIDE OF DASH) CLASS 2 DATA LINK CONNECTOR (DLC) (BELOW DASH, LEFT OF STEERING COLUMN) FUSIBLE LINK (10 GA-RUST) GEN BATT FUSE GEN TERMINAL F INPUT GEN TERMINAL L CONTROL GENERATOR GRY WIRE HOT AT ALL TIMES HOT IN ACC, RUN, START INSTRUMENT PANEL CLUSTER (IPC) IPC/BFC ACC FUSE LEFT I/P FUSE BLOCK (BEHIND LEFT SIDE OF DASH) ORG/ WIRE POWER DISTRIBUTION SYSTEM POWERTRAIN CONTROL MODULE (PCM) (BEHIND LEFT SIDE OF DASH) PPL PPL PPL PPL SERIAL DATA CLASS 2 RED WIRE SERIAL DATA SOLID STATE STARTER SOLENOID UNDERHOOD FUSE BLOCK (IN LEFT SIDE OF ENGINE COMPARTMENT, ON STRUT TOWER) VOLTS IND
