Oldsmobile Alero I (1999-2004) odometer reset input Wiring diagram
This page shows the only wiring diagram for the component.odometer reset input, which is found in the car Oldsmobile Alero I (1999-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram odometer reset input (1 of 1)
1440 1807 PPL
2.4L
3.4L
ABS INDICATOR
AIR BAG IND
BATT CLASS 2
BLK WIRE
BLK/WHT WIRE
BODY COMPUTER SYSTEM
BODY CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
BRAKE INDICATOR
BRN/WHT WIRE
CHANGE OIL INDICATOR
CHECK TIRE PRESSURE INDICATOR
CLASS 2 (BCM)
CLASS 2 (BCM/EBCM)
CLASS 2 (EBCM)
CLASS 2 (IPC/BCM)
CLASS 2 (PCM/BCM)
CLASS 2 (SDM)
CRUISE INDICATOR
DK BLU WIRE
ELECTRONIC BRAKE CONTROL MODULE (INSIDE LEFT FRONT FENDER)
ENGINE COOLANT TEMPERATURE GAUGE
FUEL GAUGE
GRY WIRE
HEADLIGHTS SYSTEM
HI BEAM INDICATOR
HOT AT ALL TIMES
HOT IN ACCY, RUN, OR START
IGN
IGN 0
ILLUMINATON
INSTRUMENT CLUSTER
IPC/BFC ACC FUSE
IPC/HVAC BATT FUSE
LEFT I/P JUNCTION BLOCK
LEFT TURN INDICATOR
LO BEAM IN
LOGIC
LOW COOLANT INDICATOR
LOW COOLANT LEVEL
LOW FUEL INDICATOR
LOW OIL INDICATOR
LOW TRACTION INDICATOR
LOW WASH INDICATOR
LT BLU WIRE
LT BLU/BLK WIRE
LT GRN WIRE
MIL CTRL
ODOMETER RESET INPUT
OIL PRESSURE INDICATOR
ORG/ WIRE
PARK BRAKE SIGNAL
PNK HI BEAM IN WIRE
POWERTRAIN CONTROL MODULE (BELOW LEFT SIDE OF DASH, NEAR STEERING COLUMN)
PPL
PPL DATA LINK CONNECTOR (BELOW DASH, LEFT OF STEERING COLUMN)
PPL PPL
PPL SERIAL DATA
PPL SERIAL DATA CLASS 2
RIGHT TURN INDICATOR
SEAT BELT INDICATOR
SECURITY INDICATOR
SERIAL DATA
SERVICE ENGINE SOON INDICATOR (MALFUNCTION INDICATOR LAMP)
SERVICE VEHICLE SOON INDICATOR
SHIFT INDICATOR (W/M/T ONLY)
SPEEDOMETER
TACHOMETER
TEMPERATURE INDICATOR
TRACTION OFF INDICATOR
TRIP ODOMETER RESET SWITCH
VOLTS INDICATOR
WASHER FLUID LEVEL
YEL/BLK WIRE
Go to component -> Instrument cluster circuit -> ODOMETER RESET INPUT
