Oldsmobile Alero I (1999-2004) manual trans- mission Wiring diagrams
This page contains all the electrical diagrams for the component. manual trans- mission, in which he is found in the car Oldsmobile Alero I (1999-2004). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram manual trans- mission (1 of 2)
AUTOMATIC TRANS- MISSION
AUTOMATIC TRANSMISSION
BATTERY
BLK WIRE
CLUTCH PEDAL POSITION (CPP) SWITCH
FUSIBLE LINK (10 GA-RUST)
GENERATOR
IGN-SW BATT 1 FUSE
IGNITION SWITCH
LOCK
MANUAL TRANS- MISSION
MANUAL TRANSMISSION
PARK/ NEUTRAL POSITION SWITCH (ON LEFT SIDE OF ENGINE)
PPL
RED WIRE
RUN WIRE
SPLICE PACK
STARTER MOTOR
STARTER SOLENOID
UNDERHOOD FUSE BLOCK (IN LEFT SIDE OF ENGINE COMPARTMENT, ON STRUT TOWER)
YEL WIRE
Go to component -> 2.2l vin f, starting circuit -> MANUAL TRANS- MISSION
Wiring diagram manual trans- mission (2 of 2)
AUTOMATIC TRANS- MISSION
AUTOMATIC TRANSMISSION
BATTERY
BLK WIRE
CLUTCH PEDAL POSITION (CPP) SWITCH
FUSIBLE LINK (10 GA-RUST)
GENERATOR
IGN-SW BATT 1 FUSE
IGNITION SWITCH
LOCK
MANUAL TRANS- MISSION
MANUAL TRANSMISSION
PARK/ NEUTRAL POSITION SWITCH (ON LEFT SIDE OF ENGINE)
PPL
RED WIRE
RUN WIRE
SPLICE PACK
STARTER MOTOR
STARTER SOLENOID
UNDERHOOD FUSE BLOCK (IN LEFT SIDE OF ENGINE COMPARTMENT, ON STRUT TOWER)
YEL WIRE
Go to component -> 3.4l vin e, starting circuit, without pcm controlled starter -> MANUAL TRANS- MISSION
