Oldsmobile Alero I (1999-2004) headlights system anti-lock brake system Wiring diagram

A/C BFC FUSE 37 A/C SYSTEM AMBIENT LIGHT SENSOR (TOP OF DASH TRIM PAD) ANTI-THEFT SYSTEM BFC BATT FUSE F BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DOOR LOCKS SYSTEM ANTI-THEFT SYSTEM COOLANT LEVEL SWITCH (RIGHT SIDE OF ENGINE COMPT) CRUISE CONTROL SYSTEM CRUISE FUSE E DK BLU WIRE DK GRN/WHT WIRE DOOR LOCK CTRL DOOR LOCK LOCK/UNLOCK SIG DRL AMBIENT LIGHT SEN LOW REF DOOR LOCKS SYSTEM DRIVER LOCK RELAY UNLOCK DRL RLY CTRL FRONT FOG LAMP SW SIG TRACTION CONTROL SW SIG WINDSHIELD WASHER FLUID LEVEL GRY/BLK WIRE HEADLAMP BEAM-LOW HEADLAMP LOW BEAM RLY CTRL FOG LAMP RLY CTRL PARK LAMP SW SIG HORN RLY CTRL HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM ANTI-LOCK BRAKE SYSTEM HEADLIGHTS SYSTEM ANTI-THEFT SYSTEM TRUNK RELEASE SYSTEM HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM EXTERIOR LIGHTS SYSTEM HORNS SYSTEM HOT AT ALL TIMES HOT IN ACC, ON OR START HOT IN ON OR START HOT IN RUN INT LPS FUSE G INTERIOR LIGHTS SYSTEM WARNING SYSTEM WARNING SYSTEM IPC/BFC ACC FUSE I LEFT FRONT DOOR AJAR SW SIG BATTERY POSITIVE VOLTAGE LEFT I/P FUSE BLOCK LOW COOLANT LEVEL IND CTRL A/C REQUEST SIG LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE OIL/ TIRE RESET SWITCH OLDSMOBILE ORG/ WIRE PARK BRAKE SWITCH PNK WIRE PNK/BLK WIRE PNK/WHT WIRE POWER DISTRIBUTION CENTER PPL PPL IGNITION 0 VOLTAGE PARK LAMP RLY CTRL RIGHT I/P FUSE BLOCK SECURITY SYST SENSOR SIG SPLICE PACK TRUNK RELEASE RLY CTRL TRUNK RELEASE SYSTEM UNDERHOOD FUSE BLOCK WASHER FLUID LEVEL SENSOR (INSIDE LEFT FRONT FENDER) WHT WIRE YEL WIRE YEL/BLK WIRE
