Oldsmobile Alero I (1999-2004) fog lamp lf Wiring diagram
This page shows the only wiring diagram for the component.fog lamp lf, which is found in the car Oldsmobile Alero I (1999-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fog lamp lf (1 of 1)
2.2L
3.4L
3.4L 2.2L
A/T SHIFT LOCK CONTROL SOLENOID
ACCESSORY POWER OUTLET (OLDS) WINDSHIELD/ WIPER MOTOR ASSEMBLY
AUXILIARY PARK LAMP LF (PONT)
AUXILIARY PARK LAMP RF (PONT)
BATTERY
BLK WIRE
BLK/WHT WIRE
BRAKE FLUID LEVEL SWITCH
CIGAR LIGHTER
CONTROL AIRFLOW MODULE (PCM) (2.2L)
COOLANT LEVEL SWITCH
COOLING FAN- RIGHT (2.2L)
CRUISE CONTROL MODULE (IF EQUIPPED)
DATA LINK CONNECTOR (DLC)
ELECTRONIC BRAKE CONTROL MODULE (EBCM)
ENGINE OIL LEVEL SWITCH (3.4L)
FOG LAMP LF
FOG LAMP RF
FUSE BLOCK (LEFT I/P)
FUSE BLOCK- UNDERHOOD
HEATED REAR OXYGEN SENSOR
HORN ASSEMBLY
I/P COMPARTMENT LAMP
I/P COMPARTMENT LAMP SWITCH
IGNITION CONTROL MODULE (ICM) (2.2L)
IGNITION CONTROL MODULE (ICM) (3.4L) BRAKE FLUID LEVEL SWITCH
MASS AIRFLOW (MAF) SENSOR (3.4L)
NCA WIRE
OLDS
PARK/NEUTRAL POSITION SWITCH (A/T)
PARK/TURN SIGNAL LAMP- LF
PARK/TURN SIGNAL LAMP- RF
POWERTRAIN CONTROL MODULE (PCM) (3.4L)
SENSOR 2 (3.4L) RADIO
SHIFT INDICATOR LAMP
SIR COIL ASSEMBLY
SPLICE PACK
STEERING WHEEL CONTROLS- RIGHT
TRACTION CONTROL SWITCH BLOWER MOTOR
TURN SIGNAL/ MULTIFUNCTION SWITCH HAZARD SWITCH
WASHER FLUID LEVEL SENSOR
WINSHIELD WASHER FLUID PUM
Go to component -> Ground distribution circuit (1 of 2) -> FOG LAMP LF
