Oldsmobile Alero I (1999-2004) door lock switch- front passenger Wiring diagram
This page shows the only wiring diagram for the component.door lock switch- front passenger, which is found in the car Oldsmobile Alero I (1999-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram door lock switch- front passenger (1 of 1)
4-WAY ADJUST
6-WAY ADJUST
AIR TEMPERATURE ACTUATOR
AUDIO AMPLIFIER
BACK-UP LAMP-RH
BACKUP LAMP (LEFT)
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM)
CENTER HIGH MOUNTED STOP LAMP (CHMSL)
DOOR AJAR SWITCH- LR
DOOR AJAR SWITCH- RR
DOOR LOCK SWITCH- DRIVER DOOR JAMB SWITCH- RF
DOOR LOCK SWITCH- FRONT PASSENGER
FOG LAMP SWITCH (IF EQUIPPED)
FUEL PUMP, SENDER ASSEMBLY DOOR JAMB SWITCH- LF
FUSE BLOCK (LEFT I/P)
HWAC CONTROL ASSEMBLY
I/P DIMMER SWITCH
IGNITION SWITCH
INSIDE REARVIEW MIRROR/ W/ READING LAMPS (IF EQUIPPED)
INSTRUMENT PANEL CLUSTER (IPC)
LAMP ASSEMBLY- LR
LAMP ASSEMBLY- RR
LICENSE LAMP DOME LAMP
NCA WIRE
OLDS
OUTSIDE REAR VIEW MIRROR SWITCH SEAT BELT SWITCH
PONT PONT
RADIO
REAR COMPARTMENT LID RELEASE ACTUATOR
REAR COMPARTMENT LID RELEASE WINDOW SWITCH- FRONT PASSENGER
REAR WINDOW DEFOGGER GRID
REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR)
SEAT ADJUSTER SWITCH DRIVER
SEDAN
SEDAN, COUPE
SPLICE PACK
SUNROOF MODULE
TRACTION CONTROL SWITCH
TRIP ODOMETER RESET SWITCH
WINDOW SWITCH- DRIVER
Go to component -> Ground distribution circuit (2 of 2) -> DOOR LOCK SWITCH- FRONT PASSENGER
