Oldsmobile Alero I (1999-2004) crnk vlt Wiring diagram
This page shows the only wiring diagram for the component.crnk vlt, which is found in the car Oldsmobile Alero I (1999-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram crnk vlt (1 of 1)
BATTERY
BLK WIRE
CRANK FUSE 54
CRNK VLT
FUSIBLE LINK (10 GA-RUST)
GENERATOR
IGN-SW BATT 1 FUSE
IGNITION SWITCH
LOCK
PARK/ NEUTRAL POSITION SWITCH (ON LEFT SIDE OF ENGINE)
POWERTRAIN CONTROL MODULE (BELOW LEFT SIDE OF DASH, NEAR STEERING COLUMN)
PPL
PPL/ SPLICE PACK
RED WIRE
RUN WIRE
START RLY
STARTER MOTOR
STARTER RELAY 1
STARTER SOLENOID
UNDER- HOOD FUSE BLOCK (IN LEFT SIDE OF ENGINE COMPT)
UNDERHOOD FUSE BLOCK (IN LEFT SIDE OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> 3.4l vin e, starting circuit, with pcm controlled starter -> CRNK VLT
