Oldsmobile Alero I (1999-2004) class 2 serial data primary ppl wiring diagram
This page shows the only wiring diagram for the component.class 2 serial data primary ppl, which is found in the car Oldsmobile Alero I (1999-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
class 2 serial data primary ppl wiring diagram (1 of 1)
AIR BAG FUSE E
AIR BAG INDICATOR
ANTI-LOCK BRAKES SYSTEM PPL
BODY CONTROL MODULE (BCM) (BEHIND RIGHT SIDE OF DASH)
CASE GROUND
CLASS 2 SERIAL DATA PRIMARY PPL
DATA LINK CONNECTOR (DLC) (PARTIAL) (BELOW DASH, LEFT OF STEERING COLUMN)
DK GRN WIRE
DK GRN/WHT WIRE
HIGH CONTROL LOW CONTROL LOW CONTROL
HIGH CONTROL SERIAL DATA
HOT IN ON OR START
IGNITION
INFLATABLE RESTRAINT I/P MODULE
INFLATABLE RESTRAINT STEERING WHEEL MODULE
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
INSTRUMENT PANEL CLUSTER (IPC)
LEFT I/P FUSE BLOCK (BEHIND LEFT SIDE OF DASH)
NCA WIRE
PPL
PPL ENGINE CONTROLS SYSTEM PPL
PPL PPL 1807 1807
SERIAL DATA CLASS 2
SHORTING BAR
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Supplemental restraint circuit -> CLASS 2 SERIAL DATA PRIMARY PPL
