Oldsmobile Achieva I (1991-1997) Instrument cluster circuit, base cluster

1995 VFTC ABS IND. AIR BAG IND ALARM FUSE ANTI-LOCK BRAKES SYSTEM B/H CONN BELTS IND BLK WIRE BLK/WHT WIRE BRAKE FLUID LEVEL SWITCH (PART OF BRAKE MASTER CYLINDER) BRAKE IND BRN WIRE BRN/WHT WIRE CHECK OIL IND DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE ENGINE CONTROLS SYSTEM ENGINE COOLANT TEMPERATURE IND ENGINE COOLANT TEMPERATURE SENDER (LEFT REAR OF ENGINE COMPARTMENT) FLOAT MAGNET FUEL GAGE FUEL GAGE SENDER (FUEL TANK UNIT) FUSE BLOCK GAGES FUSE GRY WIRE HI-BEAM IND HOT AT ALL TIMES HOT IN RUN, BULB TEST OR START ILLUM (4 USED) INSTRUMENT CLUSTER INSTRUMENT CLUSTER CONNECTORS) LEFT TURN IND LOW COOLANT IND LOW COOLANT SWITCH (ON SURGE TANK) LT BLU WIRE LT GRN (OR WHT) WIRE LT GRN/BLK WIRE MAL- FUNCTION IND NOT USED GROUND OIL LEVEL SWITCH (ON OIL PAN) OIL PRESSURE IND ORG/ WIRE PARK BRAKE SWITCH (ABOVE PARK BRAKE) PNK WIRE PPL RIGHT TURN IND SENDER INPUT LO OIL BUFFER SOLID STATE SPEEDOMETER STARTING/CHARGING SYSTEM SUPPLEMENTAL RESTRAINTS SYSTEM INTERIOR LIGHTS SYSTEM TAN WIRE TAN/WHT WIRE TEMPERATURE GAGE VOLTS IND WARNING SYSTEM WHT WIRE YEL/BLK WIRE
