Oldsmobile Achieva I (1991-1997) 4 speed auto transaxle Wiring diagram
This page shows the only wiring diagram for the component.4 speed auto transaxle, which is found in the car Oldsmobile Achieva I (1991-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 4 speed auto transaxle (1 of 1)
3 SPEED AUTO TRANSAXLE
4 SPD A/T 3 SPD A/T
4 SPEED AUTO TRANSAXLE
B/H CONN
BLK/WHT WIRE
BRAKE SW (BEHIND DASH, ON BRAKE PEDAL SUPPORT)
BRN WIRE
BUICK W/ CONSOLE
BUICK W/O CONSOLE
ERLS
FUSE BLOCK
GRY WIRE
HOT IN RUN, BULB TEST OR START
LT GRN WIRE
PNK (OR LT GRN) WIRE
PNK WIRE
PPL
SHIFT INTERLOCK SYSTEM
SHIFT SOLENOID
TAN/BLK WIRE
TCC PWM SOLENOID
TORQUE CONVERTER CLUTCH SOLENOID
TRANSAXLE CONVERTER CLUTCH
TRANSAXLE POSITION SW
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Wiring diagram engine performance 2.3l (vin d)s (3 of 3) -> 4 SPEED AUTO TRANSAXLE
