Nissan X-Trail III facelift (2017-2024) Tire pressure monitoring circuit

BCM (BODY CONTROL MODULE) BLK WIRE BLU WIRE BUZZER CAN L CAN-H COMBINATION METER COMPUTER DATA LINES SYSTEM DRIVER SIDE FRONT TIRE PRESSURE SENSOR FUSE 14 FUSE 31 FUSE 13 FUSE 7 FUSE BLOCK (J/B) HOT AT ALL TIMES HOT IN ON OR START IGN LEFT REAR TIRE PRESSURE SENSOR PASSENGER SIDE FRONT TIRE PRESSURE SENSOR PNK WIRE PPL PPL/GRN WIRE PWR ECU RIGHT END OF DASH) RIGHT REAR TIRE PRESSURE SENSOR SHORTING PIN TIRE PRESSURE IND UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY) WHT WIRE
