Car Wiring Diagrams for Defoggers circuit for Nissan X-Trail III facelift (2017-2024)

A/C AUTO AMPLIFIER A/C SWITCH AUTO ACC AUTOMATIC A/C BCM (BODY CONTROL MODULE) BLK WIRE BLU WIRE CAN L CAN-H COMPUTER DATA LINES SYSTEM DEF RL D DOOR MIRROR DEFOGGER FRONT AIR CONTROL FUSE 14 FUSE 20 FUSE 22 FUSE 23 FUSE 24 FUSE 7 FUSE BLOCK (J/B) FUSIBLE LINK BOX (BATTERY) FUSIBLE LINK E GND 2 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ACC OR ON HOT IN ON OR START IGN TEMPO LEFT DOOR MIRROR LIN SW AMP LT BLU WIRE LT GRN WIRE MANUAL A/C PPL PPL/GRN WIRE PPL/RED WIRE PWR ECU REAR WINDOW DEFOGGER REAR WINDOW DEFOGGER CONDENSER REAR WINDOW DEFOGGER RELAY RED WIRE RIGHT DOOR MIRROR RIGHT END OF DASH) SHORTING PIN TAN WIRE W/ HEATED MIRRORS WHT WIRE YEL WIRE
