Nissan X-Trail III facelift (2017-2024) lh vert mir sens Wiring diagram
This page shows the only wiring diagram for the component.lh vert mir sens, which is found in the car Nissan X-Trail III facelift (2017-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lh vert mir sens (1 of 1)
AUTOMATIC DRIVE POSITIONER CONTROL UNIT
BACKWARD
BAT (PTC)
BCM (BODY CONTROL MODULE)
BLK WIRE
BLU WIRE
BRN WIRE
BWD FWD
CAN L
CAN-H
CIRCUIT BREAKER 2
COMPUTER DATA LINES SYSTEM
FORWARD/
FUSE 14
FUSE 6
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK, RELAY BOX 1
FUSIBLE LINK N
GND PWR
GND SENS GND
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT FRONT DOOR SWITCH
LH COM MIR MTR
LH HORIZ MIR MTR
LH HORIZ MIR SENS
LH MIR SELECT SW
LH VERT MIR MTR
LH VERT MIR SENS
LT BLU WIRE
LT GRN WIRE
LUMBAR SUPPORT MOTOR
LUMBAR SUPPORT SWITCH
MIR SW (DOWNWARD)
MIR SW (LEFTWARD)
MIR SW (RIGHTWARD)
MIR SW (UPWARD)
PPL
PPL/GRY WIRE
RED WIRE
RH COM MIR MTR
RH HORIZ MIR MTR
RH HORIZ MIR SENS
RH MIR SELECTOR SW
RH VERT MIR MTR
RH VERT MIR SENS
SHORTING PIN
TAN WIRE
UART (TX/RX)
WHT WIRE
YEL WIRE
Go to component -> Memory systems circuit (1 of 3) -> LH VERT MIR SENS
