Nissan X-Trail III facelift (2017-2024) left front combination lamp -turn signal Wiring diagram
This page shows the only wiring diagram for the component.left front combination lamp -turn signal, which is found in the car Nissan X-Trail III facelift (2017-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front combination lamp -turn signal (1 of 1)
A/C COMPRESSOR
A/C RELAY
ACTIVE GRILLE SHUTTER
BLK WIRE
BRAKE FLUID LEVEL SWITCH
BRN WIRE
COOLING FAN RELAY 1
DISTANCE SENSOR
EPS CONTROL UNIT
FRONT WIPER HIGH RELAY
FRONT WIPER MOTOR
FRONT WIPER RELAY
FUEL PUMP RELAY
GRY WIRE
HIGH BEAM
HOOD SWITCH
HORN
HORN (LOW)
IGNITION COIL 1, 2, 3, 4 (W/ POWER TRANSISTOR)
INPUT SPEED SENSOR
INTAKE MANIFOLD RUNNER CONTROL VALVE MOTOR SHIELD
INTELLIGENT KEY WARNING BUZZER
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LED DAYTIME, PARKING LAMP CONTROL MODULE
LED HEADLAMP CONTROL UNIT
LEFT FRONT COMBINATION LAMP
LEFT FRONT COMBINATION LAMP -TURN SIGNAL
LEFT FRONT FOG LAMP
LOW BEAM
NCA WIRE
OUTPUT SPEED SENSOR
PRIMARY SPEED SENSOR
RIGHT FRONT COMBINATION LAMP
RIGHT FRONT COMBINATION LAMP TURN SIGNAL
RIGHT FRONT FOG LAMP
SIDE MARKER
STARTER RELAY
TCM (TRANSMISSION CONTROL MODULE)
THROTTLE CONTROL MOTOR RELAY
W/ HALOGEN HEADLAMPS
W/ INTELLIGENT KEY SYSTEM
W/ LED HEADLAMPS
WASHER FLUID LEVEL SWITCH
Go to component -> Ground distribution circuit (2 of 4) -> LEFT FRONT COMBINATION LAMP -TURN SIGNAL
