Nissan X-Trail III facelift (2017-2024) gnd ext Wiring diagram
This page shows the only wiring diagram for the component.gnd ext, which is found in the car Nissan X-Trail III facelift (2017-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram gnd ext (1 of 1)
ABS ACTUATOR, ELECTRIC UNIT (CONTROL UNIT)
ABS/TCS/VDC CONTROL UNIT
ACTUATOR
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
COMPUTER DATA LINES SYSTEM
FL IN
FL OUT
FL RR IN
FR IN
FR OUT
FR-RL IN
FUSE 21
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK, RELAY BOX 1
FUSIBLE LINK H
FUSIBLE LINK L
GND (ECU)
GND EXT
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ ACCESSORY RELAY ENERGIZED
LEFT FRONT WHEEL SENSOR
LEFT REAR WHEEL SENSOR
LT BLU WIRE
LT GRN WIRE
MOTOR
MOTOR RELAY
PNK WIRE
PPL
PPL/BLU WIRE
RED WIRE
RELAY UNIT
RIGHT REAR WHEEL SENSOR
RL IN
RL OUT
RR IN
RR OUT
SHIELD
SOLENOID VALVE RELAY
TAN WIRE
USV EXT
VAC
VDC OFF
VDC OFF SWITCH
WAU
WHT WIRE
WSP FL
WSP FR
WSP RL
WSP RR
WSS FL
WSS RL
WSS RR
YEL WIRE
Go to component -> Anti-lock brakes circuit (1 of 2) -> GND EXT
