Nissan X-Trail III facelift (2017-2024) front auxiliary input jack Wiring diagram
This page shows the only wiring diagram for the component.front auxiliary input jack, which is found in the car Nissan X-Trail III facelift (2017-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front auxiliary input jack (1 of 1)
A/C AUTO AMP
A/C SWITCH
AIR BAG DIAGNOSIS SENSOR UNIT
AROUND VIEW MONITOR CONTROL UNIT
AUDIO UNIT
AUTOMATIC A/C
AUTOMATIC BACK DOOR SWITCH
AUTOMATIC DRIVE POSITIONER CONTROL UNIT
AV CONTROL UNIT
AWD LOCK SWITCH
BCM (BODY CONTROL MODULE)
BLK WIRE
CANADA
COMBINATION SWITCH (SPIRAL CABLE)
COMBINATION SWITCH (WIPER, WASHER SWITCH)
CONSOLE POWER SOCKET
DONGLE UNIT
DOOR MIRROR REMOTE CONTROL SWITCH
ECO MODE SWITCH
ELECTRIC PARKING BREAK SWITCH
FRONT AIR CONTROL
FRONT AUXILIARY INPUT JACK
FRONT PASSENGER AIR BAG OFF INDICATOR
FRONT POWER SOCKET
FUEL LID DOOR OPENER SWITCH
GLOVE BOX LAMP)
GRY WIRE
HAZARD SWITCH
HEATED STEERING WHEEL
HEATED STEERING WHEEL SWITCH
KEY SWITCH
LANE INTERVENTION SWITCH
LEFT BLIND SPOT WARNING INDICATOR
LEFT DOOR MIRROR
LEFT FRONT DOOR LOCK ASSEMBLY
LEFT FRONT HEATED SEAT SWITCH
LEFT FRONT OUTSIDE HANDLE ASSEMBLY
MAIN POWER WINDOW, DOOR LOCK/ UNLOCK SWITCH
MANUAL A/C
MAP LAMP ASSEMBLY
METER CONTROL SWITCH
NATS ANTENNA AMP
PPL/BLK WIRE
PUSH BUTTON IGNITION SWITCH
RED WIRE
RIGHT FRONT HEATED SEAT SWITCH
SEAT MEMORY SWITCH
SPORT MODE SWITCH
STEERING ANGLE SENSOR
STEERING ASSIST SWITCH
STEERING SWITCHES
VDC OFF SWITCH
W/ DRIVER ASSISTANCE SYSTEM
W/ FRONT HEATED SEATS
W/ INTELLIGENT KEY SYSTEM
W/ MEMORY
W/ NAVIGATION SYSTEM
W/ PROPILOT ASSIST
W/O INTELLIGENT KEY SYSTEM
W/O MEMORY
YEL WIRE
Go to component -> Ground distribution circuit (3 of 4) -> FRONT AUXILIARY INPUT JACK
