Nissan X-Trail III facelift (2017-2024) def rl d Wiring diagram
This page shows the only wiring diagram for the component.def rl d, which is found in the car Nissan X-Trail III facelift (2017-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram def rl d (1 of 1)
A/C AUTO AMPLIFIER
A/C SWITCH
AUTO ACC
AUTOMATIC A/C
BCM (BODY CONTROL MODULE)
BLK WIRE
BLU WIRE
CAN L
CAN-H
COMPUTER DATA LINES SYSTEM
DEF RL D
DOOR MIRROR DEFOGGER
FRONT AIR CONTROL
FUSE 14
FUSE 20
FUSE 22
FUSE 23
FUSE 24
FUSE 7
FUSE BLOCK (J/B)
FUSIBLE LINK BOX (BATTERY)
FUSIBLE LINK E
GND 2
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON OR START
IGN TEMPO
LEFT DOOR MIRROR
LIN SW AMP
LT BLU WIRE
LT GRN WIRE
MANUAL A/C
PPL
PPL/GRN WIRE
PPL/RED WIRE
PWR ECU
REAR WINDOW DEFOGGER
REAR WINDOW DEFOGGER CONDENSER
REAR WINDOW DEFOGGER RELAY
RED WIRE
RIGHT DOOR MIRROR
RIGHT END OF DASH)
SHORTING PIN
TAN WIRE
W/ HEATED MIRRORS
WHT WIRE
YEL WIRE
Go to component -> Defoggers circuit -> DEF RL D
