Nissan Versa III (2019-2022) warning buzzer sig gnd steering vib motor sig Wiring diagram
This page shows the only wiring diagram for the component.warning buzzer sig gnd steering vib motor sig, which is found in the car Nissan Versa III (2019-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram warning buzzer sig gnd steering vib motor sig (1 of 1)
ADAS CONTROL UNIT (RIGHT END OF DASH)
AEB IND
AEB OFF SW SIG
AEB OFF SWITCH
AEB SW SIG
BLK WIRE
BLU WIRE
BRAKE PEDAL POSITION SWITCH
BRN WIRE
CAN L
CAN-H
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DRIVER ASSISTANCE BUZZER (W/ DRIVER ASSISTANCE SYSTEM)
EARLY PRODUCTION
FUSE 18
FUSE 24
FUSE 26
FUSE 3
FUSE BLOCK (J/B)
GND WARNING BUZZER SIG
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ ACCESSORY RELAY-1 ENERGIZED
HOT W/ IGNITION RELAY-2 ENERGIZED
IC CAN H
IC CAN L
IGN
ITS CAN-H
ITS CAN-L
LATE PRODUCTION
LDW SW SIG
LDW SWITCH
LT BLU WIRE
LT GRN WIRE
LWD SW SIG
OUT SPEED SENS
OUTPUT SPEED SENSOR
PNK WIRE
POWER SUPPLY
PPL
PRI SPEED SENS
PRIMARY SPEED SENSOR
RAB OFF SWITCH (LATE PRODUCTION)
RAB SW SIG
REB OFF IND
RED WIRE
SEC SPEED SENS
SECONDARY SPEED SENSOR
SET IND
SHIFT INTERLOCK SYSTEM
STEERING VIB MOTOR SIG
STOP LAMP SWITCH (ON BRAKE PEDAL BRACKET)
TAN WIRE
TCM (TRANSMISSION CONTROL MODULE)
UNIFIED METER CONTROL UNIT CRUISE IND (W/ INFORMATION DISPLAY)
V CAN-H
V CAN-L
WARNING BUZZER SIG GND STEERING VIB MOTOR SIG
WARNING SYSTEM BUZZER (W/ AUTOMATIC EMERGENCY BRAKING SYSTEM) (ABOVE GLOVE BOX)
WHT WIRE
YEL WIRE
Go to component -> Cruise control circuit (2 of 2) -> WARNING BUZZER SIG GND STEERING VIB MOTOR SIG
