Nissan Versa III (2019-2022) sec led Wiring diagrams

This page contains all the electrical diagrams for the component. sec led, in which he is found in the car Nissan Versa III (2019-2022). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram sec led (1 of 4)

Wiring diagram sec led for Nissan Versa III (2019-2022) (1 of 4)

Get lifetime access to Nissan Versa III (2019-2022)

BLK WIRE BLU WIRE BRN WIRE BUZZER CAN L CAN-H COMBINATION METER COMPUTER DATA LINES SYSTEM EARLY PRODUCTION FUSE 44 FUSE, FUSIBLE LINK, RELAY BOX FUSIBLE LINK BOX (BATTERY) FUSIBLE LINK E GRN WIRE GRY WIRE HORN (LOW) HORN RELAY HORNS SYSTEM HOT AT ALL TIMES LATE PRODUCTION LEFT ACCESSORY PRE-WIRE LEFT FRONT DOOR SWITCH LEFT REAR DOOR SWITCH LOCK LT BLU WIRE LT GRN WIRE MAIN POWER WINDOW, DOOR LOCK/UNLOCK SWITCH NATS ANTENNA AMP PNK WIRE PPL PUSH BUTTON IGNITION SWITCH PUSH SWITCH RED WIRE RIGHT FRONT DOOR SWITCH RIGHT POWER WINDOW, DOOR LOCK/ UNLOCK SWITCH RIGHT REAR DOOR SWITCH SEC LED SECURITY IND STOP LAMP SWITCH TAN WIRE UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY) UNLOCK WHT WIRE YEL WIRE

Go to component -> Forced entry circuit (4 of 4) -> SEC LED

Wiring diagram sec led (2 of 4)

Wiring diagram sec led for Nissan Versa III (2019-2022) (2 of 4)

Get lifetime access to Nissan Versa III (2019-2022)

BCM (BODY CONTROL MODULE) BLU WIRE BUZZER CAN L CAN-H COMBINATION METER COMPUTER DATA LINES SYSTEM CONTROL UNIT) DISPLAY EARLY PRODUCTION FUSE 19 FUSE 26 FUSE BLOCK (J/B) GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ IGNITION RELAY-2 ENERGIZED IGN INTELLIGENT KEY UNIT LATE PRODUCTION LEFT ACCESSORY PRE-WIRE LT BLU WIRE NATS ANTENNA AMPLIFIER PNK WIRE PUSH BUTTON IGNITION SWITCH PWR ECU RED WIRE RIGHT END OF DASH) SEC LED SECURITY SECURITY IND SECURITY LED UNIFIED METER WHT WIRE

Go to component -> Immobilizer circuit, w/ intelligent key unit -> SEC LED

Wiring diagram sec led (3 of 4)

Wiring diagram sec led for Nissan Versa III (2019-2022) (3 of 4)

Get lifetime access to Nissan Versa III (2019-2022)

BATTERY BCM (BODY CONTROL MODULE) BLK WIRE BLU WIRE BUZZER CAN L CAN-H CLK IMMO COMBINATION METER COMPUTER DATA LINES SYSTEM CONTROL UNIT) DATA IMMO DATA IMMO CLK IMMO DISPLAY EARLY PRODUCTION FUSE 16 FUSE 26 FUSE 9 FUSE BLOCK (J/B) GND 2 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ IGNITION RELAY-2 ENERGIZED IGN LATE PRODUCTION LEFT ACCESSORY PRE-WIRE LT BLU WIRE NATS ANTENNA AMPLIFIER PNK WIRE PWR ECU RED WIRE SEC LED SECURITY SECURITY IND SECURITY LED UNIFIED METER WHT WIRE

Go to component -> Immobilizer circuit, w/o intelligent key unit -> SEC LED
