Nissan Versa III (2019-2022) data immo clk immo Wiring diagram
This page shows the only wiring diagram for the component.data immo clk immo, which is found in the car Nissan Versa III (2019-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram data immo clk immo (1 of 1)
BATTERY
BCM (BODY CONTROL MODULE)
BLK WIRE
BLU WIRE
BUZZER
CAN L
CAN-H
CLK IMMO
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CONTROL UNIT)
DATA IMMO
DATA IMMO CLK IMMO
DISPLAY
EARLY PRODUCTION
FUSE 16
FUSE 26
FUSE 9
FUSE BLOCK (J/B)
GND 2
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGNITION RELAY-2 ENERGIZED
IGN
LATE PRODUCTION
LEFT ACCESSORY PRE-WIRE
LT BLU WIRE
NATS ANTENNA AMPLIFIER
PNK WIRE
PWR ECU
RED WIRE
SEC LED
SECURITY
SECURITY IND
SECURITY LED
UNIFIED METER
WHT WIRE
Go to component -> Immobilizer circuit, w/o intelligent key unit -> DATA IMMO CLK IMMO
