Nissan Versa III (2019-2022) analog input 10 Wiring diagram
This page shows the only wiring diagram for the component.analog input 10, which is found in the car Nissan Versa III (2019-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram analog input 10 (1 of 1)
A/C AUTO AMPLIFIER (FRONT OF CENTER CONSOLE)
AIR MIX DOOR MOTOR (LEFT SIDE OF HVAC UNIT)
ANALOG INPUT 10
ANALOG INPUT 10 (BLOWER FEEDBACK)
BLK WIRE
BLK/WHT WIRE
BLOWER (+) GND
BLOWER FEEDBACK
BLOWER PWM
BRN WIRE
EVAP SENSOR (+)
FRONT BLOWER MOTOR
FRONT BLOWER MOTOR RELAY
FUSE 19
FUSE 35
FUSE 37
FUSE BLOCK (J/B)
FUSIBLE LINK BOX (BATTERY)
FUSIBLE LINK H
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
IGNITION
INTAKE SENSOR (LEFT SIDE OF HVAC UNIT)
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK WIRE
PPL
RED WIRE
RIGHT END OF DASH)
TAN WIRE
VARIABLE BLOWER CONTROL (TOP LEFT OF HVAC UNIT)
WHT WIRE
YEL WIRE
Go to component -> Automatic a/c circuit (1 of 3) -> ANALOG INPUT 10
