Car Wiring Diagrams for Charging circuit for Nissan Versa II facelift (2014-2019)

ALT C BAT CURT SENS BATTERY BATTERY CURRENT SENSOR BATTERY TEMPERATURE SENSOR BLK WIRE BLK/GRY WIRE BLK/RED WIRE BLU WIRE BLU/WHT WIRE BRN WIRE CAN L CAN-H CHARGE INDICATOR COMBINATION METER COMPUTER DATA LINES SYSTEM CVT FUSE 24 FUSE 3 FUSE BLOCK (J/B) FUSE, FUSIBLE LINK BOX FUSIBLE LINK A FUSIBLE LINK BOX (BATTERY) FUSIBLE LINK D GENERATOR GRN WIRE GRY WIRE HATCHBACK, SEDAN LATE PRODUCTION SEDAN EARLY PRODUCTION HOT IN ON OR START IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) NCA WIRE ORG/ WIRE PNK CAN-L WIRE PNK WIRE PPL RED WIRE S GND SEDAN HATCHBACK SENS GND SENS PWR SPLY TBATT BATT TEMP SENS WHT WIRE YEL WIRE
