Car Wiring Diagrams for Immobilizer circuit for Nissan Versa II facelift (2014-2019)

BAT (F/L) BAT FUSE BCM (BODY CONTROL MODULE) BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H COMBINATION METER COMPUTER DATA LINES SYSTEM ECM (ENGINE CONTROL MODULE) FUSE 12 FUSE 2 FUSE 53 FUSE 8 FUSE BLOCK (J/B) FUSE, FUSIBLE LINK BOX FUSIBLE LINK G GRN WIRE HOT AT ALL TIMES HOT IN ON OR START IGN SW IMMOB ONE WAY COMMUNICATION IMMOB TOW WAY COMMUNICATION IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) LT GRN WIRE NATS ANTENNA AMPLIFIER ORG/ WIRE PNK LT WIRE PNK WIRE RED WIRE SECURITY IND SECURITY IND OUTPUT YEL WIRE
