Nissan Versa II facelift (2014-2019) trunk back door open output wiring diagram
This page shows the only wiring diagram for the component.trunk back door open output, which is found in the car Nissan Versa II facelift (2014-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
trunk back door open output wiring diagram (1 of 1)
BAT (F/L)
BCM (BODY CONTROL MODULE)
BLK WIRE
BLU WIRE
CAN L
CAN-H
CANADA
COMBINATION METER
COMPUTER DATA LINES SYSTEM
EARLY PRODUCTION
FUSE 14
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK BOX
FUSIBLE LINK G
GRN WIRE
HOT AT ALL TIMES
INTELLIGENT TUNER
KEYLESS TUNER POWER SUPPLY
KEYLESS TUNER RSSI
KEYLESS TUNER SIGNAL
KEYLESS, AUTO LIGHT SENS GND
LATE PRODUCTION
LT GRN WIRE
PNK WIRE
PPL
RED WIRE
REMOTE KEYLESS ENTRY RECEIVER
RIGHT END OF DASH)
TRUNK BACK DOOR OPEN OUTPUT
TRUNK LID LOCK ASSEMBLY
TRUNK LID OPENER ACTUATOR
TRUNK LID OPENER SWITCH
TRUNK LID SWITCH
TRUNK REQUEST SW
TRUNK ROOM LP SW
UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY)
USA
W/ INTELLIGENT KEY SYSTEM
W/O INTELLIGENT KEY SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Trunk release circuit -> TRUNK BACK DOOR OPEN OUTPUT
