Nissan Versa II facelift (2014-2019) ppl ods input Wiring diagram
This page shows the only wiring diagram for the component.ppl ods input, which is found in the car Nissan Versa II facelift (2014-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ppl ods input (1 of 1)
AIR BAG DIAGNOSIS SENSOR UNIT
BLK WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
CAN-H PNK CAN-L WIRE
COMPUTER DATA LINES SYSTEM
CUTOFF TELLTALE PPL AIR BAG W/L PNK WIRE
FUSE 3
FUSE 7
FUSE BLOCK (J/B)
GRN WIRE
GRY WIRE
HOT IN ON OR START
LEFT FRONT DOOR SATELLITE SENSOR
LEFT SIDE AIR BAG SATELLITE SENSOR
LEFT SIDE CURTAIN AIR BAG MODULE
LH B-PILLAR SAT SENS (-) PPL
LH DOOR SAT SENS (-) PNK LH DOOR SAT SENS (+) WIRE
LH SEAT BELT BUCKLE SW (+)
LH SENS (+)
LT GRN WIRE
NCA WIRE
ORG/ WIRE
PNK IGN WIRE
PNK WIRE
PPL
PPL ODS INPUT
RED WIRE
RH B-PILLAR SAT SENS (-)
RH DOOR SAT SENS (-)
RH SEAT BELT BUCKLE SW (+)
RIGHT FRONT DOOR SATELLITE SENSOR
RIGHT FRONT SEAT BELT PRE-TENSIONER
RIGHT FRONT SIDE AIR BAG MODULE
RIGHT SIDE AIR BAG SATELLITE SENSOR
RIGHT SIDE CURTAIN AIR BAG MODULE
S-RH (-)
SEAT BELT REMIND
SHIELD
SHIELD GND PNK RH DOOR SAT SENS (+) WIRE
TAN WIRE
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Supplemental restraints circuit (1 of 3) -> PPL ODS INPUT
