Nissan Versa II facelift (2014-2019) input 1 pnk output 5 ppl output 4 Wiring diagram
This page shows the only wiring diagram for the component.input 1 pnk output 5 ppl output 4, which is found in the car Nissan Versa II facelift (2014-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram input 1 pnk output 5 ppl output 4 (1 of 1)
BAT (F/L)
BAT (FUSE) GND
BCM (BODY CONTROL MODULE)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRAKE IND
BRN WIRE
CAN L
CAN-H
CAN-H PNK CAN-L WIRE
COMBINATION METER
COMBINATION SWITCH (LIGHTING, TURN SIGNAL SWITCH)
COMPUTER DATA LINES SYSTEM
CPU FR FOG RELAY
DAYTIME LIGHT RELAY 1
DAYTIME LIGHT RELAY 2 (IN RELAY HOLDER ABOVE FUSE BLOCK (J/B))
DR SW (DR)
DR SW (RL)
DR SW (RR)
DTRL RLY
FRONT FOG LAMP RELAY
FUSE 12
FUSE 3
FUSE 31
FUSE 34
FUSE 35
FUSE 37
FUSE 40
FUSE 41
FUSE 8
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK BOX
FUSIBLE LINK BOX (BATTERY)
FUSIBLE LINK E
FUSIBLE LINK G
GND (ILL)
GND (PWR) GND (CIRCUIT)
GRN WIRE
GRY WIRE
HEADLAMP HIGH
HEADLAMP HIGH RELAY
HEADLAMP LOW
HEADLAMP LOW RELAY
HIGH BEAM IND
HOT AT ALL TIMES
HOT IN ON OR START
IGN
INPUT 1 PNK OUTPUT 5 PPL OUTPUT 4 WIRE
INPUT 2
INPUT 3
INPUT 4
INPUT 5
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LEFT FRONT COMBINATION LAMP
LEFT FRONT FOG LAMP
LT BLU WIRE
LT GRN WIRE
OUTPUT 1
OUTPUT 2
OUTPUT 3
PARKING BRAKE SWITCH
PNK DR SW (AS) WIRE
PNK WIRE
PPL
PRE-WIRING FOR FRONT FOG LAMPS
PRK BRK SW SIG
RED WIRE
RIGHT FRONT COMBINATION LAMP
RIGHT FRONT FOG LAMP
S GND
UNIFIED METER CONTROL UNIT
W/ INTELLIGENT KEY SYSTEM
W/O INTELLIGENT KEY SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Headlights circuit, w/ drl -> INPUT 1 PNK OUTPUT 5 PPL OUTPUT 4 WIRE
