Car Wiring Diagrams for Courtesy lamps circuit for Nissan Versa II (2012-2014)

13 12 46 45 DOOR SW (RR) DOOR SW (AS) PNK WIRE 15 18 PPL 38 37 IGN SW KEY SW 39 40 CAN-H CAN-L PNK WIRE 48 47 DOOR SW (RL) DOOR SW (DR) BAT (F/L) BAT FUSE BAT SAVER BLK WIRE BLU WIRE BODY CONTROL MODULE (BCM) (BEHIND LEFT BRN WIRE COMPUTER DATA LINES SYSTEM DOOR END OF DASH) FUSE 12 FUSE 2 FUSE 8 (UNDER LEFT END OF DASH) FUSE BLOCK (J/B) FUSE, FUSIBLE LINK BOX (LEFT REAR OF ENGINE COMPT) FUSIBLE LINK G GRN WIRE HOT AT ALL TIMES HOT IN ON OR START INTERIOR ROOM LAMP LT BLU WIRE LT GRN WIRE LUGGAGE LAMP MAP LAMP (IF EQUIPPED) OFF ON ORG/ WIRE PNK WIRE PPL RED WIRE RIGHT FRONT DOOR SWITCH (RIGHT FRONT "B" PILLAR) RIGHT REAR DOOR SWITCH (RIGHT REAR "C" PILLAR) ROOM LAMP OUT TRUNK LID SWITCH TRUNK/GLASS PNK HATCH SW WIRE W/ INTELLIGENT KEY SYSTEM W/O INTELLIGENT KEY SYSTEM WHT WIRE YEL WIRE
