Car Wiring Diagrams for Immobilizer circuit for Nissan Versa II (2012-2014)

39 40 39 40 CAN-H CAN-L 70 57 67 BAT (F/L) BAT (FUSE) GND 84 83 CAN-H CAN-L BCM (BODY CONTROL MODULE) (BEHIND LEFT END OF DASH) BLK WIRE BLU WIRE BRN WIRE COMBINATION METER COMPUTER DATA LINES SYSTEM PNK WIRE COMPUTER PNK DATA LINES SYSTEM WIRE ECM (ENGINE CONTROL MODULE) (LEFT REAR OF ENGINE COMPT) FUSE GRN WIRE HOT AT ALL TIMES HOT AT ALL TIMES FUSE BLOCK (J/B) FUSE HOT IN ON OR START IGN SW IMMOB TOW WAY COMMUNICATION LT GRN WIRE NATS ANTENNA AMPLIFIER (BEHIND (RIGHT SIDE SIDE END OF DASH) OF STEERING COLUMN) ORG/ WIRE PNK WIRE RED WIRE SECURITY IND SECURITY IND OUTPUT IMMOB ONE WAY COMMUNICATION YEL WIRE
