Nissan Versa II (2012-2014) Forced entry circuit, w/ intelligent key unit

AT DEVICE OUTPUT BACK DOOR ANTENNA - BATT SAVER OUTPUT BATTERY (F/L) BCM (BODY CONTROL MODULE) (BEHIND LEFT END OF DASH) BLK WIRE BLU WIRE BRAKE SW 1 BRAKE SW 2 BRN WIRE CAN L CAN-H CENTRAL DOOR LOCK SW CENTRAL DOOR UNLOCK SW COMPUTER DATA LINES SYSTEM CVT SHIFT SELECTOR (PARK POSITION SWITCH) DOOR ANTENNA (AS) + DOOR ANTENNA (DR) + DOOR LOCK OUTPUT DOOR SW (AS) DOOR SW (DR) DOOR SW (RL) DOOR SW (RR) DOOR UNLOCK COMMON (DR) DOOR UNLOCK OUTPUT (AS) DR UNLOCK OUTPUT (RR, RL) ENGINE START SWITCH FUSE 14 FUSE 2 FUSE 30 FUSE 8 FUSE BLOCK (J/B) FUSE, FUSIBLE LINK BOX FUSIBLE LINK G GRN WIRE GRY WIRE HAZARD SWITCH HOT AT ALL TIMES HOT IN ON OR START INTELLIGENT TUNER KEY CYLINDER LOCK SW KEY CYLINDER UNLOCK SW KEYLESS TUNER AUTO LIGHT KEYLESS TUNER POWER SPLY KEYLESS TUNER RSSI KEYLESS TUNER SIG LEFT FLASHER OUTPUT LEFT FRONT DOOR LOCK KEY CYLINDER SWITCH LOCK UNLOCK LT BLU WIRE LT GRN WIRE LUGGAGE LAMP OUTPUT ORG/ WIRE OUTSIDE KEY ANTENNA (REAR BUMPER) PNK WIRE POW POSI LED (LOC POSI LED) PPL PPL CANADA PPL USA RED WIRE REQUEST SWITCH (AS) REQUEST SWITCH (DR) RIGHT FLASHER OUTPUT ROOM ANTENNA 1- ROOM ANTENNA 2+ ROOM ANTENNA 3- ROOM LAMP OUTPUT SECURITY IND SENSOR GND SHIFT P POSI PARK POSI SW SMART KEYLESS BUZZ OUTPUT STOP LAMP SWITCH TRUNK, TAILGATE, FUEL DOORS SYSTEM TRUNK/BACK DR OPEN OUTPUT WHT WIRE YEL WIRE

BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM GRN WIRE GRY WIRE HORNS SYSTEM INSIDE KEY ANTENNA (CONSOLE) INSIDE KEY ANTENNA (INSTRUMENT CENTER) INTELLIGENT KEY WARNING BUZZER IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) LEFT FRONT OUTSIDE HANDLE LT BLU WIRE LT GRN WIRE OUTSIDE KEY ANTENNA PNK WIRE PPL RED WIRE REQUEST SWITCH RIGHT FRONT OUTSIDE HANDLE WHT WIRE YEL WIRE

BLK WIRE BLK/WHT WIRE BLU WIRE BRN WIRE BUZZER CANADA COMPUTER DATA LINES SYSTEM GRN WIRE GRY WIRE INSIDE KEY ANTENNA (TRUNK ROOM) KEY IND LEFT "C" PILLAR) LEFT FRONT DOOR SWITCH LEFT REAR DOOR SWITCH LT BLU WIRE LT GRN WIRE PNK WIRE PPL RED WIRE REMOTE KEYLESS ENTRY RECEIVER RIGHT FRONT DOOR SWITCH RIGHT REAR DOOR SWITCH SECURITY IND SHIELD UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY) USA USA (OR PPL) USA CANADA USA PPL WHT WIRE

ACC/ON BLK WIRE BLK/WHT WIRE BLU WIRE BRN WIRE GRN WIRE GRY WIRE LEFT FRONT DOOR LOCK ACTUATOR LEFT REAR DOOR LOCK ACTUATOR LOCK LT BLU WIRE LT GRN WIRE MAIN POWER WINDOW, DOOR LOCK/UNLOCK SWITCH PPL PUSH BUTTON IGNITION SWITCH PUSH SWITCH RED WIRE RIGHT FRONT DOOR LOCK ACTUATOR RIGHT POWER WINDOW, DOOR LOCK/UNLOCK SWITCH RIGHT REAR DOOR LOCK ACTUATOR UNLOCK WHT WIRE
