Nissan Versa II (2012-2014) navigation, sound systems cooling fans, air conditioning systems Wiring diagram
This page shows the only wiring diagram for the component.navigation, sound systems cooling fans, air conditioning systems, which is found in the car Nissan Versa II (2012-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram navigation, sound systems cooling fans, air conditioning systems (1 of 1)
ACC/ ON
ACCESSORY RELAY 2 (LEFT END OF DASH)
ANTI-LOCK BRAKES SYSTEM
ANTI-THEFT SYSTEM
BLK WIRE
BLU WIRE
BLWR MTR RLY OUTPUT
BRN WIRE
ELECTRONIC POWER STEERING SYSTEM
ENG STRT SW
FROM BLOWER RELAY (DIAGRAM 2 OF 3)
FROM FUSE, FUSIBLE LINK BOX (DIAGRAM 2 OF 3)
FROM FUSIBLE LINK BOX (BATTERY) (DIAGRAM 1 OF 3)
FROM IGNITION SWITCH (DIAGRAM 2 OF 3)
FUSE
FUSE 14
FUSE 18
FUSE 24
FUSE 30
FUSE BLOCK (J/B) (UNDER LEFT END OF DASH)
FUSE FUSE 29
FUSE, FUSIBLE LINK BOX (LEFT REAR OF ENGINE COMPT)
FUSIBLE LINK F FUSIBLE LINK G
FUSIBLE LINK H
FUSIBLE LINK J
FUSIBLE LINK M FUSIBLE LINK I
GRN WIRE
GRY WIRE
HEADLIGHTS SYSTEM
IGN RLY OUTPUT 2
IGNITION RELAY 2
ILL
INSTRUMENT CLUSTER, NAVIGATION, BODY COMPUTER SYSTEMS
LT BLU WIRE
LT GRN WIRE
NAVIGATION, SOUND SYSTEMS COOLING FANS, AIR CONDITIONING SYSTEMS
ORG/ WIRE
PNK WIRE
PPL
PPL PWR POSITION LED
PUSH BUTTON IGNITION SWITCH (W/ INTELLIGENT KEY SYSTEM)
PUSH SWITCH
RED WIRE
RLY OUTPUT
STARTING/ CHARGING, HORNS SYSTEMS
TO FUSE 2 (DIAGRAM 2 OF 3)
TO FUSE BLOCK (J/B) (DIAGRAM 2 OF 3)
TO IGNITION SWITCH (DIAGRAM 2 OF 3)
TRANSMISSIONS SYSTEM
W/ INTELLIGENT KEY SYSTEM
W/O INTELLIGENT KEY SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (3 of 3) -> NAVIGATION, SOUND SYSTEMS COOLING FANS, AIR CONDITIONING SYSTEMS
