Nissan Versa II (2012-2014) left flasher output Wiring diagrams
This page contains all the electrical diagrams for the component. left flasher output, in which he is found in the car Nissan Versa II (2012-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
left flasher output wiring diagram (1 of 2)
AT DEVICE OUTPUT
BACK DOOR ANTENNA -
BATT SAVER OUTPUT
BATTERY (F/L)
BCM (BODY CONTROL MODULE) (BEHIND LEFT END OF DASH)
BLK WIRE
BLU WIRE
BRAKE SW 1
BRAKE SW 2
BRN WIRE
CAN L
CAN-H
CENTRAL DOOR LOCK SW
CENTRAL DOOR UNLOCK SW
COMPUTER DATA LINES SYSTEM
CVT SHIFT SELECTOR (PARK POSITION SWITCH)
DOOR ANTENNA (AS) +
DOOR ANTENNA (DR) +
DOOR LOCK OUTPUT
DOOR SW (AS)
DOOR SW (DR)
DOOR SW (RL)
DOOR SW (RR)
DOOR UNLOCK COMMON (DR)
DOOR UNLOCK OUTPUT (AS)
DR UNLOCK OUTPUT (RR, RL)
ENGINE START SWITCH
FUSE 14
FUSE 2
FUSE 30
FUSE 8
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK BOX
FUSIBLE LINK G
GRN WIRE
GRY WIRE
HAZARD SWITCH
HOT AT ALL TIMES
HOT IN ON OR START
INTELLIGENT TUNER
KEY CYLINDER LOCK SW
KEY CYLINDER UNLOCK SW
KEYLESS TUNER AUTO LIGHT
KEYLESS TUNER POWER SPLY
KEYLESS TUNER RSSI
KEYLESS TUNER SIG
LEFT FLASHER OUTPUT
LEFT FRONT DOOR LOCK KEY CYLINDER SWITCH
LOCK UNLOCK
LT BLU WIRE
LT GRN WIRE
LUGGAGE LAMP OUTPUT
ORG/ WIRE
OUTSIDE KEY ANTENNA (REAR BUMPER)
PNK WIRE
POW POSI LED (LOC POSI LED)
PPL
PPL CANADA
PPL USA
RED WIRE
REQUEST SWITCH (AS)
REQUEST SWITCH (DR)
RIGHT FLASHER OUTPUT
ROOM ANTENNA 1-
ROOM ANTENNA 2+
ROOM ANTENNA 3-
ROOM LAMP OUTPUT
SECURITY IND
SENSOR GND
SHIFT P POSI PARK POSI SW
SMART KEYLESS BUZZ OUTPUT
STOP LAMP SWITCH
TRUNK, TAILGATE, FUEL DOORS SYSTEM
TRUNK/BACK DR OPEN OUTPUT
WHT WIRE
YEL WIRE
Go to component -> Forced entry circuit, w/ intelligent key unit (1 of 4) -> LEFT FLASHER OUTPUT
