Nissan Versa II (2012-2014) can jumper 1 can +2 can jumper 2 Wiring diagrams

This page contains all the electrical diagrams for the component. can jumper 1 can +2 can jumper 2, in which he is found in the car Nissan Versa II (2012-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram can jumper 1 can +2 can jumper 2 (1 of 3)

Wiring diagram can jumper 1 can +2 can jumper 2 for Nissan Versa II (2012-2014) (1 of 3)

Get access

12 11 10 PPL 18 19 SHIELD 33 34 BT ANTENNA BT SHIELD SHIELD 8 P/R AUDIO L+ AUDIO R- AUDIO RTN BLK WIRE BLU WIRE BLUETOOTH ANTENNA BLUETOOTH CONTROL UNIT BRN WIRE CAN JUMPER 1 CAN +2 CAN JUMPER 2 CAN L CAN-H CHARGE CHARGER COMBINATION METER COMBINATION SWITCH (SPIRAL CABLE) COMPUTER DATA LINES SYSTEM CONT 6 SPEED MIC POWER DETECT DIGITAL EARLY PRODUCTION FUSE 5 FUSE BLOCK (J/B) (UNDER LEFT END OF DASH) GRN WIRE GRY WIRE HOT IN ON OR START IDENTIFY IGN GND ILLUM IPOD CONNECTOR IPOD SENS/ LAD-OUT 1 LAD-OUT 2 LAD-OUT 3 (GND) PPL LATE PRODUCTION LT BLU WIRE LT GRN WIRE MICROPHONE (CENTER FRONT OF ROOF) ORG/ WIRE PHONE/ END PHONE/ SEND PNK WIRE PPL PWR RED WIRE SEEK SEEK SOURCE UP DOWN SHIELD SHIELD PNK 4 6 5 SHIELD WIRE STEERING WHEEL AUDIO CONTROL SWITCHES UNIFIED METER CONTROL UNIT USD D- VOLUME VOLUME DOWN UP WHT WIRE YEL WIRE

Go to component -> Mid-line radio circuit (2 of 2) -> CAN JUMPER 1 CAN +2 CAN JUMPER 2

Wiring diagram can jumper 1 can +2 can jumper 2 (2 of 3)

Wiring diagram can jumper 1 can +2 can jumper 2 for Nissan Versa II (2012-2014) (2 of 3)

Get access

33 34 BT ANTENNA BT SHIELD SHIELD 7 8 MIC IN + MIC IN -(GND) SHIELD BLK WIRE BLU WIRE BLUETOOTH ANTENNA BLUETOOTH CONTROL UNIT BRN WIRE CAN JUMPER 1 CAN +2 CAN JUMPER 2 CAN-H- CAN-L- COMBINATION METER COMBINATION SWITCH (SPIRAL CABLE) COMPUTER DATA LINES SYSTEM CONT 2 CONT 4 CONT 5 CONT 6 SPEED MIC POWER EARLY PRODUCTION FUSE 5 FUSE BLOCK (J/B) (UNDER LEFT END OF DASH) GRY WIRE HOT IN ON OR START IGN GND ILLUM LATE PRODUCTION LT BLU WIRE LT GRN WIRE MICROPHONE (CENTER FRONT OF ROOF) ORG/ WIRE PHONE/ VOLUME SEND DOWN PNK WIRE RED WIRE RIGHT REAR DOOR SPEAKER SEEK DOWN SEEK SOURCE UP SHIELD SHIELD PNK 4 6 5 SHIELD WIRE SPEED OUT 8 STEERING WHEEL AUDIO CONTROL SWITCHES UNIFIED METER CONTROL UNIT VOLUME PHONE/ UP END WHT WIRE YEL WIRE

Go to component -> Navigation circuit (2 of 2) -> CAN JUMPER 1 CAN +2 CAN JUMPER 2
