Nissan Versa I (2006-2012) pnk computer data lines pnk system Wiring diagram

70 57 BAT FL BAT FUSE A/T SHIFT SELECTOR (W/ 4-SPEED A/T) CVT SHIFT SELECTOR (IF EQUIPPED) AUDIO UNIT (W/ AUDIO UNIT) AV CONTROL UNIT (W/ PREMIUM AUDIO) BLK WIRE BLU WIRE BODY CONTROL MODULE (BCM) (BEHIND RIGHT BRN WIRE CAN-H- CAN-L- COMBINATION METER COMBINATION SWITCH COMPUTER DATA LINES SYSTEM DOOR MIRROR VDC OFF REMOTE CONTROL SWITCH SWITCH (IF EQUIPPED) FRONT AIR CONTROL FUSE 20 FUSE 37 FUSE 8 FUSE FUSE 53 FUSIBLE LINK BOX (BATTERY) FUSIBLE LINK G GND POWER GND SIG GRN WIRE GRY WIRE HAZARD SWITCH HOT AT ALL TIMES HOT AT ALL TIMES FUSE, FUSIBLE LINK BOX (LEFT FRONT OF ENGINE COMPT) HOT AT CPU ALL TIMES +IG FUSIBLE LINK D GND (PWR) HOT IN ACC OR ON HOT IN ON OR START FUSE BLOCK (J/B) FUSE 6 (UNDER LEFT END OF DASH) ILLUMINATION CONTROL SWITCH ILLUMINATION STEERING WHEEL AUDIO CONTROL SWITCHES (IF EQUIPPED) LT BLU WIRE LT GRN WIRE MICROPHONE (BLUETOOTH) (CENTER FRONT OF ROOF) NCA WIRE OF ENGINE COMPT) ORG/ WIRE PNK COMPUTER DATA LINES PNK SYSTEM WIRE PNK WIRE PPL RED WIRE SIDE OF DASH) SPIRAL CABLE (COMBINATION SWITCH) (IN STEERING COLUMN) TAIL LAMP RELAY TAIL/L RLY WHT WIRE YEL WIRE
